| Performance Parameters | |
|---|---|
| Power supply | 220-240V 50-60Hz |
| Drying time sec | 4-6 |
| Airflow rate (m/s) | 98 |
| Air volume m3/min | 2.8 |
| Rated current (A) | 3.0-3.2 |
| Power consumption (W) | 550 |
| Noise (dB) | 58 |
| Motor type | Brushless DC motor |
| Safety components | -Thermal Fuse -Overcurrent breaker |
| Power cord | None (Terminal block connection) |
| External dimensions(mm) | Width:300 Depth:219 Height:670 |
| Weight(kg) | 11 |
| Drain tank(L) | 0.8 |
| Model Name | Power supply | Model | Heater | Drying time sec |
Airflow rate (m/s) |
Air volume m3/min |
Rated current (A) |
Power consumption (W) |
Noise (dB) |
Motor type | Safety components |
Power cord | External dimensions (mm) |
Weight (kg) |
Drain tank (L) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| JT-SB216JSH | 220-240V 50-60Hz |
High | ON | 3-4 | 106 | 3.1 | 5.7-6.2 | 1240 | 61 | Brushless DC motor |
-Thermal Fuse -Overcurrent breaker |
None (Terminal block connection |
Width:300 Depth:219 Height:670 |
11 | 0.8 |
| OFF | 3-5 | 3.9-4.2 | 720 | ||||||||||||
| Standard | ON | 3-5 | 98 | 2.8 | 4.9-5.3 | 1070 | 58 | ||||||||
| OFF | 4-6 | 3.0-3.2 | 550 |
