AIRVISION

Capacity : 2.5 Tr

Refrigerant : R410A

MRP : ₹ 152000

Features

Vertical Vane

Grooved Piping

Drain Pump

Failure Recall Function

Filter Check Signal

High Ceiling Mode

Long Life Filter

Self Diagnostic Function

Auto Fan Speed Mode

Low Ceiling Mode

PAM (Pulse Amplitude Modulation)

Vector Wave Eco Inverter

Magnetic Flux Vector Sine Wave Drive

Demand Function (Onsite Adjustment)

Heat Caulking Fixing Method

Joing Lap DC Motor

DC Fan Motor

Auto Restart

On/Off Operation Timer

Pure White

Horizontal Vane

Technical Specifications

Type (Cooling)
Indoor Unit
PSY-SP30KA
Outdoor Unit
SUY-SA30VA2

Performance Parameters
Power Supply(Indoor Unit)	1 phase 220-240V 50Hz
Power Supply(Outdoor Unit)	1 ph 220-240V 50Hz
Cooling Capacity(Min-Max)	8.8(3.8-8.8)kW
Total Input	2.56kW
EER (W/W)	3.44
ISEER (W/W)	4.36
Airflow (CFM) (Low/Mid2/Mid1/High)-Indoor	885/990/1060
Airflow (CFM)-Outdoor	1800
Guaranteed Operating Range Upper Limit(DB)	52
Guaranteed Operating Range Lower Limit(DB)	18

Compressor, Refrigerant & Ambient Operations
Noise Level Indoor (Low/Mid2/Mid1/High) In dB(A)	45/49/51
Noise Level Outdoor In dB(A)	54
Refrigerant	R410A

Dimensions & Weight
Indoor unit	Dimensions (H x W x D)	mm	1900x600x360
Indoor unit	Weight	kg	46
Outdoor unit	Dimensions (H x W x D)	mm	880x840x330
Outdoor unit	Weight	kg	50
Ext.Piping	Diameter Liquid	mm (inches)	9.52
	Diameter Gas	mm (inches)	15.88
	Max. piping length	m	30
	Max. height difference	m	15

Capacity : 3 Tr

Refrigerant : R410A

MRP : ₹ 177000

Features

Vertical Vane

Grooved Piping

Drain Pump

Failure Recall Function

Filter Check Signal

High Ceiling Mode

Long Life Filter

Self Diagnostic Function

Auto Fan Speed Mode

Low Ceiling Mode

PAM (Pulse Amplitude Modulation)

Vector Wave Eco Inverter

Magnetic Flux Vector Sine Wave Drive

Demand Function (Onsite Adjustment)

Heat Caulking Fixing Method

Joing Lap DC Motor

DC Fan Motor

Auto Restart

On/Off Operation Timer

Pure White

Horizontal Vane

Technical Specifications

Type (Cooling)
Indoor Unit
PSY-SP36KA
Outdoor Unit
PUY-SP36YKA2

Performance Parameters
Power Supply(Indoor Unit)	1 phase 220-240V 50Hz
Power Supply(Outdoor Unit)	3 phase 380-415V 50Hz
Cooling Capacity(Min-Max)	10.6(4.0-10.6)kW
Total Input	3.65kW
EER (W/W)	2.90
ISEER (W/W)	3.83
Airflow (CFM) (Low/Mid2/Mid1/High)-Indoor	885/990/1060
Airflow (CFM)-Outdoor	2648
Guaranteed Operating Range Upper Limit(DB)	52
Guaranteed Operating Range Lower Limit(DB)	18

Compressor, Refrigerant & Ambient Operations
Noise Level Indoor (Low/Mid2/Mid1/High) In dB(A)	45/49/51
Noise Level Outdoor In dB(A)	52
Refrigerant	R410A

Dimensions & Weight
Indoor unit	Dimensions (H x W x D)	mm	1900x600x360
Indoor unit	Weight	kg	48
Outdoor unit	Dimensions (H x W x D)	mm	981x1050x330
Outdoor unit	Weight	kg	65
Ext.Piping	Diameter Liquid	mm (inches)	9.52
	Diameter Gas	mm (inches)	15.88
	Max. piping length	m	50
	Max. height difference	m	30

Capacity : 3.5 Tr

Refrigerant : R410A

MRP : ₹ 192000

Features

Vertical Vane

Grooved Piping

Drain Pump

Failure Recall Function

Filter Check Signal

High Ceiling Mode

Long Life Filter

Self Diagnostic Function

Auto Fan Speed Mode

Low Ceiling Mode

PAM (Pulse Amplitude Modulation)

Vector Wave Eco Inverter

Magnetic Flux Vector Sine Wave Drive

Demand Function (Onsite Adjustment)

Heat Caulking Fixing Method

Joing Lap DC Motor

DC Fan Motor

Auto Restart

On/Off Operation Timer

Pure White

Horizontal Vane

Technical Specifications

Type (Cooling)
Indoor Unit
PSY-SP42KA
Outdoor Unit
PUY-SP42YKA2

Performance Parameters
Power Supply(Indoor Unit)	1 phase 220-240V 50Hz
Power Supply(Outdoor Unit)	3 phase 380-415V 50Hz
Cooling Capacity(Min-Max)	12.3(6.1-12.3)kW
Total Input	4.06kW
EER (W/W)	3.02
ISEER (W/W)	3.81
Airflow (CFM) (Low/Mid2/Mid1/High)-Indoor	885/990/1060
Airflow (CFM)-Outdoor	2648
Guaranteed Operating Range Upper Limit(DB)	52
Guaranteed Operating Range Lower Limit(DB)	18

Compressor, Refrigerant & Ambient Operations
Noise Level Indoor (Low/Mid2/Mid1/High) In dB(A)	45/49/51
Noise Level Outdoor In dB(A)	53
Refrigerant	R410A

Dimensions & Weight
Indoor unit	Dimensions (H x W x D)	mm	1900x600x360
Indoor unit	Weight	kg	48
Outdoor unit	Dimensions (H x W x D)	mm	981x1050x330
Outdoor unit	Weight	kg	73
Ext.Piping	Diameter Liquid	mm (inches)	9.52
	Diameter Gas	mm (inches)	15.88
	Max. piping length	m	50
	Max. height difference	m	30

Capacity : 4 Tr

Refrigerant : R410A

MRP : ₹ 212000

Features

Vertical Vane

Grooved Piping

Drain Pump

Failure Recall Function

Filter Check Signal

High Ceiling Mode

Long Life Filter

Self Diagnostic Function

Auto Fan Speed Mode

Low Ceiling Mode

PAM (Pulse Amplitude Modulation)

Vector Wave Eco Inverter

Magnetic Flux Vector Sine Wave Drive

Demand Function (Onsite Adjustment)

Heat Caulking Fixing Method

Joing Lap DC Motor

DC Fan Motor

Auto Restart

On/Off Operation Timer

Pure White

Horizontal Vane

Technical Specifications

Type (Cooling)
Indoor Unit
PSY-SP48KA
Outdoor Unit
PUY-SP48YKA2

Performance Parameters
Power Supply(Indoor Unit)	1 phase 220-240V 50Hz
Power Supply(Outdoor Unit)	3 phase 380-415V 50Hz
Cooling Capacity(Min-Max)	13.4(6.7-13.4)kW
Total Input	5.86kW
EER (W/W)	2.28
ISEER (W/W)	3.34
Airflow (CFM) (Low/Mid2/Mid1/High)-Indoor	885/990/1060
Airflow (CFM)-Outdoor	3071
Guaranteed Operating Range Upper Limit(DB)	52
Guaranteed Operating Range Lower Limit(DB)	18

Compressor, Refrigerant & Ambient Operations
Noise Level Indoor (Low/Mid2/Mid1/High) In dB(A)	45/49/51
Noise Level Outdoor In dB(A)	56
Refrigerant	R410A

Dimensions & Weight
Indoor unit	Dimensions (H x W x D)	mm	1900x600x360
Indoor unit	Weight	kg	48
Outdoor unit	Dimensions (H x W x D)	mm	981x1050x330
Outdoor unit	Weight	kg	73
Ext.Piping	Diameter Liquid	mm (inches)	9.52
	Diameter Gas	mm (inches)	15.88
	Max. piping length	m	50
	Max. height difference	m	30
